Fully Automatic Carton Box Making Machine, Heaven And Earth Cover Box Forming Machine
Description:
The Automatic Paper Box Making Machine adopts motion controller, visual manipulator for positioning ,HMI System,which make it possible that paper feeding, gluing, cardboard four corners taping, feeding, edge covering, full ear folding, forming and shaping of the finished box are completed in one operation.Through the electronic cam gear rack structure driving the box mold to operate, it can independently complete multiple deep folding operations so as to meet the requirements of high-end products and boxes free of folding trace in the market.
Automatic Rigid Box Forming Machine Parameters:
| Model |
ZY-450F |
| Max. size of box |
450*400*110mm |
| Min. size of box |
45*45*8mm |
| Folding-in Depth |
110mm |
| Power consumption |
2.52KW |
| Speed |
0-20pcs/min |
| Voltage |
AC220V 50Hz |
| Air consumption |
8L/min 0.65Mpa |
| Weight |
700kg |
| Measurement |
1150x1000x1900mm |
features :
The machine is stable and easy to maintain.
The motor is controlled by the frequency converter. It saves electricity and helps stabilize work.
Grinding machines are provided on both sides of the machine to make the glue more stable and firm.
When there is no material, the machine will slow down and stop running to reduce waste.
The system is continuous, accurate and automated.
Good rigidity, compact structure and easy operation.
Performance and features:
The advanced motion controller makes it easier to operate and smoother, especially for box coating.
Use hot melt adhesive to make the paste more tight and perfect.
The whole machine action is completed by servo pneumatic, PLC programming control, and the operation is stable.
The multi-function boxing mode completes the folding angle, the centering angle and left and right folding angles.
The four-side foaming structure adopts double guide rail and screw adjustment, and the positioning and accurate debugging are convenient and efficient.
Application range:
This machine is designed for packaging boxes, such as jewellery box, gift box, mobile box, tea box,etc.
All of the relevant products are internationally high-end products, low breakdown, high accuracy.
Quality Team:
Quality inspection from raw material to production, and delilvery.
Professional quality control person, to avoid the unqualified products flowing to customer.
Strict inspection to Raw material, production, and delivery.
Full series of equipments in quality laboratory.
Continuous improvement, seeking higher quality level.
Primary products:
Automatic Rigid Box Making Machine
Automatic Paper Box Making Machine
Jewellery Box Making Machine
Box Forming Machine
Box Assembly Machine
Corner Pasting Machine
Paper Gluing Machine
Automatic Grooving Machine
Etc.
